웜기어 감속기 / NMRV, NRV

Size : 025-030-040-050-063-075-090-105-130-150
Reduction Ratio : 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 80, 100
Motor power : 0.06~15kW
Torque : 2.7~1958Nm
장 점 : 자체 냉각 방식 디자인
Casing Material : Aluminum casing for NMRV 025~105 & Cast Iron for NMRV 130~150
Paint specification : Orange-peel blue epoxy-polyester RAL5010. (Except for 025 : not-painted)
Stock management : More than 20,000 of worm gear reducers are available at all times. Ready-to-assembled kits for HBS series are always available.
